More customized diode laser modules with different wavelengths and power options are available additionally to the standard types.



Brand: FU

Model: FU650AL200-GD1669, FU635AL120-GD1669, FU637AL1200-GD1669, FU638AL700-GD1669, FU639AL2200-GD1669

Projection Type : Line

Projection Fan angle (°, full angle): <90

Line lens: Glass cylindrical lens



Wavelength(nM) and output power: 650±10nm(0-200mW), 635±10nm(0-120mW), 637±10nm(0-1200mW), 638±10nm(0-700mW), 639±10(0-2200mW)

Operating Voltage(VDC): 3-5(<=100mW) or 9-24(>100mW)

Operating Temperature Range (°C): -10 to +40

Storage Temperature Range (°C): -20 to +50

Laser Head Dimensions (mm): 69.5(L) x16(D)

---------------------------------------------------------------

Package Includes:

Laser module -1 piece

Power supply- 1 piece

Tripod(Bracket/Mount)- 1 piece



FU-Lasers for you!
