Product Title：FU650D5-XYD1250 640-660nm 0.1~5mW red point dot laser module pointer fixed focus, small fan angle <0.5mrad
More customized diode laser modules with different wavelengths and power options are available additionally to the standard types.
Brand: FU
Model: FU650D5-XYD1250
Dot specification：
Wavelength(nM): 650±10 red color
Output Power (mW): 0.1~5
Operating Voltage(VDC): 3~5
Projection Type : Dot/Point
Beam focus: Dot shape fixed
Divergence (mrad, full angle): <0.5
Dot diameter: 2.5mm at 10meter, 10mm at 100meter(Middle of dot)
Transverse Mode : Near TEM00
Operating Temperature Range (°C): -10 to +40
Storage Temperature Range (°C): -20 to +50
Total Power Consumption (W) 1
Cooling Method : Passive air
Standard Warranty (months): 12
Laser Head Dimensions (mm): 50(L) x 12(D)
------------------
Package Includes:
Laser module -1 piece
Power supply- 1 piece
Tripod(Bracket/Mount)- 1 piece
FU650AD5-XYD1250 640-660nm 0.1~5mW red point dot laser pointer fixed focus, small fan angle <0.5mrad
FU650AD5-XYD1250,640-660nm,red laser,red dot laser, dot laser, point laser, red point laser, pointer laser, point laser module, diode laser, diode module laser, laser pointer, laser diode module, laser pointer,red laser pointer, red pointer,adjustable dot laser
