Product Title：FU63511C10-BD22 10mW Cross Line Laser 635nm 10mW cross hair line laser light projector module lazer lamp

FU63511C10-BD22 10mW Cross Line Laser 635nm

Brand: FU(For You)

Model: FU63511C10-BD22

Cross hair line specification:

Wavelength(nM): 635±10

Output Power (mW): <10

Operating Voltage(VDC): 3~5

Projection Type : Cross hair line

Beam focus: Adjustable

Projection Fan Angle(°, full angle) : 10~110

Divergence (mrad, full angle): <2

Transverse Mode : Near TEM00

Operating Temperature Range (°C): -10 to +40

Storage Temperature Range (°C): -20 to +50

Total Power Consumption (W) 1

Cooling Method : Passive air

Cable length(cm): <100

Standard Warranty (months): 12

Laser Head Dimensions (mm): 110(L) x 22(D)

------------------

Package Includes:

Laser module -1 piece

Power supply- 1 piece

Tripod(Bracket/Mount)- 1 piece

BD22 20180416-2.jpg BD22 20180416.jpg
