Product Title：FU660AD400-FGD16(Dot) FU660AL400-FGD16(Line) FU660AC400-FGD16(Cross) 9-25VDC 650-660nm 400mW red laser diode module light locator
FU660AD400-FGD16(Dot) FU660AL400-FGD16(Line) FU660AC400-FGD16(Cross) 9-25VDC 650-660NM 400mW red laser diode module light locator
More customized diode laser modules with different wavelengths and power options are available additionally to the standard types.
Brand: FU(For You)
Model: FU660AD400-FGD16(DOT)
Projection Type : Dot/spot/point
----------------------------------------------------
Model: FU660AL400-FGD16(LINE)
Projection Type : Line
Projection Fan angle (°, full angle): <110
----------------------------------------------------
Model: FU660AC400-FGD16(CROSS)
Projection Type : Cross hair Line
Projection Fan angle (°, full angle): <110
---------------------------------------------------
Different model but in same parameter:
Wavelength(nM): 660±10
Output Power (mW): <400
Operating Voltage(VDC): 9-25
Beam focus: Adjustable
Divergence (mrad, full angle): <2
Operating Temperature Range (°C): -10 to +40
Storage Temperature Range (°C): -20 to +50
Cooling Method : Passive air+Extra heat sink
Cable length(cm): <100
Standard Warranty (months): 6
Laser Head Dimensions (mm): 70(L) x 16(D)
Package Includes:
Laser module -1 piece
Power supply 1-12VDC- 1 piece
Power supply -1 piece
Notice: It need add heat-sink if work > 30 seconds.
