Product Title：FU830AD1200-GD22 820-840nm 830nm <1200 22x110mm adjustable IR infrared invisible Dot/spot/point laser diode module light lamp source

More customized diode laser modules with different wavelengths and power options are available additionally to the standard types.

Brand: FU(For You)

Model: FU830AD1200-GD22

Dot specification:

Wavelength(nM): 830±10

Output Power (mW): <1200

Operating Voltage(VDC): 9-25

Projection Type : Dot/spot/point

Beam focus: Adjustable

Divergence (mrad, full angle): <2

Transverse Mode : Near TEM00

Operating Temperature Range (°C): -10 to +40

Storage Temperature Range (°C): -20 to +50

Total Power Consumption (W): 2

Cooling Method : Extra heat sink

Cable length(cm): <100

Standard Warranty (months): 6

Laser Head Dimensions (mm): 110(L) x 22(D)

------------------

Package Includes:

Laser module -1 piece

Power supply- 1 piece

Tripod(Bracket/Mount)- 1 piece

FULASER-PROFESSIONAL LASER PRODUCT MANUFACTORY.

FU830AD1200-GD22 820-840nm 830nm <1200 22x110mm adjustable IR infrared invisible Dot/spot/point laser diode module light lamp source
