Product Title：FU785AD2000-F100/FU785AD3000-F100/FU792AD2000-F100/FU792AD3000-F100/FU808AD3000-F100/FU808AD3000-F100/FU808AD5000-F100/FU808AD8000-F100/FU808AD10000-F100/FU830AD1000-F100/FU830AD2000-F100/FU860AD1000-F100/FU860AD2000-F100 785nm 792nm 808nm 830nm 860n

Note: Different model have different wavelength and output power

Model

FU785AD2000-F100 785nm 2000mW
FU785AD3000-F100 785nm 3000mW
FU792AD2000-F100 792nm 2000mW
FU792AD3000-F100 792nm 3000mW
FU808AD2000-F100 808nm 2000mW
FU808AD3000-F100 808nm 3000mW
FU808AD5000-F100 808nm 5000mW
FU808AD8000-F100 808nm 8000mW
FU808AD10000-F100 808nm 10000mW
FU830AD1000-F100 830nm 1000mW
FU830AD2000-F100 830nm 2000mW
FU860AD1000-F100 860nm 1000mW
FU860AD2000-F100 860nm 2000mW
FU860AD3000-F100 860nm 3000mW
FU860AD5000-F100 860nm 5000mW
FU880AD2000-F100 880nm 2000mW
Wavelength See above
Spatial Mode Near TEM00
Output Power See above
Operation Mode CW or Modulation
Beam Height 29mm
Beam Size 4.5*4mm
Beam Divergence(full angle) 1.2*0.5mrad
Power Stability <3% per 4 hours
Temperature Stabilizing TEC
Warm Up Time <1 minute
MTTF 10,000 hours
Laser Head Dimension 114*44*65mm3 L*W*H
Power Supply 179*148*56mm3 L*W*H 85-265VAC 50/60Hz input
Modulation 0~30KHz Analog or TTL





FU785AD2000-F100/FU785AD3000-F100/FU792AD2000-F100/FU792AD3000-F100/FU808AD3000-F100/FU808AD3000-F100/FU808AD5000-F100/FU808AD8000-F100/FU808AD10000-F100/FU830AD1000-F100/FU830AD2000-F100/FU860AD1000-F100/FU860AD2000-F100/FU860AD3000-F100/FU860AD5000-F100/FU860AD5000-F100 ir laser CW/TTL 30KHz <3% power stability TEM00 TEC
