Measurement range
Acceleration: 0.1~199.9m/s
Velocity: 0.1~1999.9mm/s rms
Displacement: 0.001~1.999mm P-P
Measuring accuracy ±5%
Vibration pickup Piezoelectric ceramic ,accelerometer(shear-type)
Frequencyrange of acceleration 10Hz~1KHz(LO);1KHz~15KHz(HI)
Frequency range of velocity 10Hz~1KHz(LO)
Frequency range of displacement 10Hz~1KHz(LO)
Lcd display 3.5 digits display
Single output AC output 2V peak(display full scale)
load impedance 10KΩ or more
earphones can be connected;
Max hold function No
Temperature selection No
Operation condition display No
Operation condition 0~40°C
Power 9V battery
Unit size 183*67*30mm
Standard quantity per carton 20PCS
Standard carton size 66.9*45.8*30.7CM
Standard carton gross weight 13.0KG
