Product Title：FU520XYD150-GD1682(Dot) 3-5VDC 505nm 515nm 520nm 500-530NM 0-150mW green small round dot/spot/point laser diode module lazer light lamp locator 16x82mm(Diameter x length)

More customized diode laser modules with different wavelengths and power options are available additionally to the standard types.

Brand: FU(For You)

----------------------------------------------------

 Model: FU515XYD5-GD1682(515nm <5mW)

----------------------------------------------------

 Model: FU505XYD35-GD1682(505nm <35mW)

----------------------------------------------------

 Model: FU520XYD35-GD1682(520nm <35mW)

----------------------------------------------------

 Model: FU520XYD85-GD1682(520nm <85mW)

----------------------------------------------------

 Model: FU520XYD150-GD1682(520nm <150mW)

 Notice: Need add heat sink if work >30 seconds

----------------------------------------------------

Different model but in same parameter:

Wavelength(nM): 520±20

Output Power (mW): <150

Operating Voltage(VDC): 2.8-5.2

Beam focus: Adjustable

Divergence (mrad, full angle): <2

Operating Temperature Range (°C): -10 to +40

Storage Temperature Range (°C): -20 to +50

Cooling Method : Passive air+heat sink

Cable length(cm): <100

Standard Warranty (months): 12

Laser Head Dimensions (mm): 82(L) x 16(D)



Package Includes:

Laser module -1 piece

Power supply 1-3VDC- 1 piece

Tripod/support/holder -1 piece





FU-Lasers for you!
