Product Title：FU520AD10-KTGD12(Dot) FU520AL10-KTGD12(Line) FU520AC10-KTGD12(CROSS) 520NM 0-10mW power adjustable green laser diode module 3-5VDC light with resistor

FU520AD10-KTGD12(Dot) FU520AL10-KTGD12(Line) FU520AC10-KTGD12 520NM 0-10mW power adjustable green laser diode module 3-5VDC light with resistor

More customized diode laser modules with different wavelengths and power options are available additionally to the standard types.

Brand: FU(For You)

Model: FU520AD10-KTGD12(DOT)
Projection Type : Dot/spot/point

----------------------------------------------------

Model: FU520AL10-KTGD12(LINE)

Projection Type : Line

Projection Fan angle (°, full angle): <110

----------------------------------------------------

Model: FU520AC10-KTGD12(CROSS)

Projection Type : Cross hair Line

Projection Fan angle (°, full angle): <110

---------------------------------------------------

Different model but in same parameter:

Wavelength(nM): 520±10

Output Power (mW): 0~10 power adjustable

Operating Voltage(VDC): 3-5

Beam focus: Adjustable

Divergence (mrad, full angle): <2

Transverse Mode : Near TEM00

Operating Temperature Range (°C): -10 to +40

Storage Temperature Range (°C): -20 to +50

Total Power Consumption (W) 1

Cooling Method : Passive air+Extra heat sink

Cable length(cm): <100

Standard Warranty (months): 6

Laser Head Dimensions (mm): 42(L) x 12(D)

Package Includes:

Laser module -1 piece

Power supply 3VDC- 1 piece

Tripod(Bracket/Mount)- 1 piece
