Product Title：FU660WG100-GD1610X10 640~665nm 650nm 660nm 100mW Diffractive optical elements(DOE) 10*10=100 Square mesh Laser Grid Matrix laser with adjustable focus

Brand: FU(For You)

Model

:

FU660WG100-GD1610X10

Wavelength: 660nm in picture (405/450/520/532/635/650/670/685nm IR for choose)

Output power: <100mW

Operating voltage: DC2.8~3.2V or 3.5~25V

Dimension: φ16*70mm

Beam mode: 10*10=100 grid(adjustable focus)

Lens: Plastics lens

Operating temperature: -10~40°C
Storage temperature: -40-80°C
Beam size: @1000mm, length: 768 mm, width: 768 mm, each small grid: 76.8*76.8 mm (proportional scaling)
