Product Title：FU650YQD100-GD16-1.7°-312,FU650YQD100-GD16-1.83°-351,FU650YQD100-GD16-2.3°-352,FU650YQD100-GD16-2.48°-097,FU650YQD100-GD16-2.7°-311,FU650YQD100-GD16-4.3°-310,FU650YQD100-GD16-4.52°-097A,FU650YQD100-GD16-5.1°-056 circle with center point laser

More customized diode laser modules with different wavelengths and power options are available additionally to the standard types.

Brand: FU(For You)

Model: FU650YQD100-GD16-0.575°-361

Beam size: circlel diameter 10mm at 100cm, about 0.575 degree

----------------------------------------------------

Model: FU650YQD100-GD16-1.7°-312

Beam size: circlel diameter 30mm at 100cm, about 1.7 degree

----------------------------------------------------

Model: FU650YQD100-GD16-1.83°-351

Beam size: circlel diameter 32mm at 100cm, about 1.83 degree

----------------------------------------------------

Model: FU650YQD100-GD16-2.3°-352

Beam size: circlel diameter 40mm at 100cm, about 2.3 degree

----------------------------------------------------

Model: FU650YQD100-GD16-2.48°-097

Beam size: circlel diameter 43mm at 100cm, about 2.48 degree

----------------------------------------------------

Model: FU650YQD100-GD16-2.7°-311

Beam size: circlel diameter 47mm at 100cm, about 2.7 degree

----------------------------------------------------

Model: FU650YQD100-GD16-4.3°-310

Beam size: circlel diameter 75mm at 100cm, about 4.3 degree

----------------------------------------------------

Model: FU650YQD100-GD16-4.52°-097A

Beam size: circlel diameter 79mm at 100cm, about 4.52 degree

----------------------------------------------------

Model: FU650YQD100-GD16-5.1°-056

Beam size: circlel diameter 89mm at 100cm, about 5.1 degree

----------------------------------------------------

Different model but in same parameter:

Wavelength(nm): 650

Output Power (mW): <100

Operating Voltage(VDC): 3-5

Beam focus: Adjustable

Transverse Mode : Near TEM00

Operating Temperature Range (°C): -10 to +40

Storage Temperature Range (°C): -20 to +50

Total Power Consumption (W) 1

Cooling Method : Passive air+Extra heat sink

Cable length(cm): <100

Standard Warranty (months): 6

Laser Head Dimensions (mm): 70(L) x 16(D)

Package Includes:

Laser module -1 piece

Power supply 1-3VDC- 1 piece

Tripod(Bracket/Mount)- 1 piece
