Product Title：FU45081WG100-GD16 440~460nm 450nm 445nm 100mW Diffractive optical elements(DOE) 9*9=81 Square mesh Laser Grid Matrix with adjustable focus

Brand: FU(For You)

Model

:

FU45081WG100-GD16

Wavelength: 450nm in picture (405/450/520/532/635/650/670/685nm IR for choose)

Output power: <100mW

Operating voltage: DC2.8~3.2V or 3.5~25V

Dimension: φ16*70mm

Beam mode: 9*9=81 grid(adjustable focus)

Lens: Plastics lens

Operating temperature: -10~40°C
Storage temperature: -40-80°C
Beam size: @1000mm, length: 728 mm, width: 728 mm, each small grid: 81*81 mm (proportional scaling)

Note: 1)The line was made by so many dots, not a continous line.
2)The line is not straight.

FU-Lasers for you!

FU45081WG100-GD16 440~460nm 450nm 445nm 100mW Diffractive optical elements(DOE) 9*9=81 grid pattern with adjustable focus
