Product Title：FU660289MTX100-GD16 640~665nm 650nm 660nm 100mW Diffractive optical elements(DOE) 17*17=289 lattice pattern with adjustable focus
Brand: FU(For You)
Model
FU660289MTX100-GD16
Wavelength: 660nm in picture (405/450/520/532/635/650/670/685nm IR for choose)
Output power: <100mW
Operating voltage: DC2.8~3.2V or 3.5~25V
Beam mode: 17*17=289 lattice(adjustable focus)
Lens: Plastics lens
Operating temperature: -10~40°C
Storage temperature: -40-80°C
Beam size: @1000mm, Length: 266mm, Width: 266mm , dot&dot Space:17mm
(proportional scaling)
FU660289MTX100-GD16 640~665nm 650nm 660nm 100mW Diffractive optical elements(DOE) 17*17=289 lattice pattern with adjustable focus
