Product Title：FU66081MTX100-GD16 640~665nm 650nm 660nm 100mW Diffractive optical elements(DOE) 9*9=81 lattice grating pattern with adjustable focus
Brand: FU(For You)
Wavelength: 660nm in picture (405/450/520/532/635/650/670/685nm IR for choose)
Output power: <100mW
Operating voltage: DC2.8~3.2V or 3.5~25V
Beam mode: 9*9=81 lattice(adjustable focus)
Lens: Plastics lens
Operating temperature: -10~40°C
Storage temperature: -40-80°C
Beam size: @100mm, Length: 9.6mm, Width: 9.6mm , dot&dot Space:1.8mm
(proportional scaling)
FU66081MTX100-GD16 640~665nm 650nm 660nm 100mW Diffractive optical elements(DOE) 9*9=81 lattice pattern with adjustable focus
