Product Title：FU4505TXY100-GD16 440~460nm 450nm 100mW Diffractive optical elements(DOE) Concentric circles pattern with adjustable focus
Brand: FU(For You)
Wavelength: 450nm in picture (405/450/520/532/635/650/670/685nm IR for choose)
Output power: <100mW
Operating voltage: DC2.8~3.2V or 3.5~25V
Beam mode: Concentric circle(adjustable focus)
Lens: Plastics lens
Operating temperature: -10~40°C
Storage temperature: -40-80°C
Beam size: @100mm, diameter:
φ
60-
φ48-
φ
32-
φ
24-
φ
12 Max-smallest(proportional scaling)
FU4505TXY100-GD16 440~460nm 450nm 100mW Diffractive optical elements(DOE) Concentric circles pattern with adjustable focus
