Product Title：FU66010201MTX100-GD16 640~665nm 650nm 660nm 100mW Diffractive optical elements(DOE) 101*101=10201 multi dot lattice pattern with adjustable focus
Brand: FU(For You)
Model
FU66010201MTX100-GD16
Wavelength: 660nm in picture (405/450/520/532/635/650/670/685nm IR for choose)
Output power: <100mW
Operating voltage: DC2.8~3.2V or 3.5~25V
Beam mode: 101*101=10201 multi dot lattice(adjustable focus)
Lens: Plastics lens
Operating temperature: -10~40°C
Storage temperature: -40-80°C
Beam size: @100mm, length: 8.7 mm, width: 8.7 mm, space: 0.09 mm (proportional scaling)
FU66010201MTX100-GD16 640~665nm 650nm 660nm 100mW Diffractive optical elements(DOE) 101*101=10201 multi dot lattice pattern with adjustable focus
