Note: Different model will have different output power.
| Model |
FU405AD400-F100 405nm 400mW(default shipping) FU405AD1000-F100 405nm 1000mW FU405AD2000-F100 405nm 2000mW FU405AD3000-F100 405nm 3000mW FU405AD4000-F100 405nm 4000mW FU355AD50-F100 355nm 50mW |
| Wavelength | See above |
| Spatial Mode | Near TEM00 |
| Output Power | See above |
| Operation Mode | CW or Modulation |
| Beam Height | 29mm |
| Beam Size | 4.5*4mm |
| Beam Divergence(full angle) | 1.2*0.5mrad |
| Power Stability | <3% per 4 hours |
| Temperature Stabilizing | TEC |
| Warm Up Time | <1 minute |
| MTTF | 10,000 hours |
| Laser Head Dimension | 114*44*65mm3 L*W*H |
| Power Supply | 179*148*56mm3 L*W*H 85-265VAC 50/60Hz input |
| Modulation | 0~30KHz Analog or TTL |
FU405AD400-F100/FU405AD1000-F100/FU405AD2000-F100/FU405AD3000-F100/FU405AD4000-F100/FU355AD50-F100 blue-violet laser 405nm 400mW 1000mW 2000mW 3000mW 4000mW/355nm 50mw
