More customized diode laser modules with different wavelengths and power options are available additionally to the standard types.



Brand: FU

Model: FU405AB100-GD832, FU450AB100-GD832, FU488AB60-GD832

Projection Type : Line

Projection Fan angle (full angle): near 10°, 20°,30°,45°,60°,75°,90°

Line lens: Glass powell lens



Wavelength(nM) and output power: 405±10nm(0-100mW), 450±10nm(0-100mW), 488±10nm(0-60mW)

Operating Voltage(VDC): 3-5

Operating Temperature Range (°C): -10 to +40

Storage Temperature Range (°C): -20 to +50

Laser Head Dimensions (mm): 32(L) x 8(D)

---------------------------------------------------------------

Package Includes:

Laser module -1 piece

Power supply- 1 piece

Tripod(Bracket/Mount)- 1 piece
