Product Title：FU450XYD1600-GD1682(Dot) 3VDC 450nm 440-460NM 0-1600mW blue small round dot/spot/point laser diode module lazer light lamp locator 16x82mm(Diameter x length)

More customized diode laser modules with different wavelengths and power options are available additionally to the standard types.

Brand: FU(For You)

----------------------------------------------------

 Model: FU450XYD5-GD1682(450nm <5mW)

----------------------------------------------------

 Model: FU450XYD50-GD1682(450nm <50mW)

----------------------------------------------------

 Model: FU450XYD80-GD1682(450nm <80mW)

----------------------------------------------------

 Model: FU450XYD100-GD1682(450nm <100mW)

----------------------------------------------------

 Model: FU450XYD500-GD1682(450nm <500mW)

 Notice: Need add heat sink if work >30 seconds

----------------------------------------------------

 Model: FU450XYD1600-GD1682(450nm <1600mW)

 Notice: Need add heat sink if work >30 seconds

----------------------------------------------------

Different model but in same parameter:

Wavelength(nM): 450±10

Output Power (mW): <1600

Operating Voltage(VDC): 2.8-3.2

Beam focus: Adjustable

Divergence (mrad, full angle): <2

Operating Temperature Range (°C): -10 to +40

Storage Temperature Range (°C): -20 to +50

Cooling Method : Passive air+heat sink

Cable length(cm): <100

Standard Warranty (months): 6

Laser Head Dimensions (mm): 82(L) x 16(D)



Package Includes:

Laser module -1 piece

Power supply- 1 piece

Tripod/support/holder -1 piece



FU-Lasers for you!
