Product Title:FU685ALX-GD10 685nm 50mW red line generator laser module adjustable focus with 5.5*2.1mm DC laser line diodes

More customized diode laser modules with different wavelengths and power options are available additionally to the standard types.
Brand: FU
Model: FU685ALX-GD10

Line specification:
Wavelength(nM): 685±10
Output Power (mW): 0.1~50
Operating Voltage(VDC): 3
Projection Type : Line
Beam focus: Adjustable
Projection Fan Angle(°, full angle) : 10~110
Divergence (mrad, full angle): <2
Transverse Mode : Near TEM00
Operating Temperature Range (°C): -10 to +40
Storage Temperature Range (°C): -20 to +50
Total Power Consumption (W) 1
Cooling Method : Passive air+Heat sink
Cable length(cm): <100
Standard Warranty (months): 6
Laser Head Dimensions (mm): 35(L) x 10(D)
------------------
Package Includes:
Laser module -1 piece
Power supply- 1 piece
Tripod(Bracket/Mount)- 1 piece





Some of laser application:

FU685ALX-GD10 685nm 50mW red line generator laser module adjustable focus with 5.5*2.1mm DC connector
FU685ALX-GD10,685nm,50mW,50mW laser,red line laser,red laser line,visible laser,liner laser,line laser, lazer line, line lazer, line generator laser, line generator lazer,- laser, - laser module, adjustable laser, straight line laser, red laser line
