Product Title：FU638AD500-F100/FU638AD1000-F100/FU638AD2000-F100/FU638AD3000-F100/FU638AD4000-F100/FU638AD5000-F100/FU638AD6000-F100/FU650AD500-F100/FU660AD1500-F100/FU664AD2000-F100/FU671AD100-F100/FU671AD200-F100 638nm 650nm 660nm 664nm 671nm red laser CW/TTL

Note: Different model have different wavelength and output power

Model

FU638AD500-F100 638nm 500mW
FU638AD1000-F100 638nm 1000mW
FU638AD2000-F100 638nm 2000mW
FU638AD3000-F100 638nm 3000mW
FU638AD4000-F100 638nm 4000mW
FU638AD5000-F100 638nm 5000mW
FU638AD6000-F100 638nm 6000mW
FU650AD500-F100 650nm 500mW
FU660AD1500-F100 660nm 1500mW
FU664AD2000-F100 664nm 2000mW
FU671AD100-F100 671nm 100mW
FU671AD200-F100 671nm 200mW
FU671AD500-F100 671nm 500mW
FU671AD800-F100 671nm 800mW
FU671AD1000-F100 671nm 1000mW
Wavelength See above
Spatial Mode Near TEM00
Output Power See above
Operation Mode CW or Modulation
Beam Height 29mm
Beam Size 4.5*4mm
Beam Divergence(full angle) 1.2*0.5mrad
Power Stability <3% per 4 hours
Temperature Stabilizing TEC
Warm Up Time <1 minute
MTTF 10,000 hours
Laser Head Dimension 114*44*65mm3 L*W*H
Power Supply 179*148*56mm3 L*W*H 85-265VAC 50/60Hz input
Modulation 0~30KHz Analog or TTL



FU638AD500-F100/FU638AD1000-F100/FU638AD2000-F100/FU638AD3000-F100/FU638AD4000-F100/FU638AD5000-F100/FU638AD6000-F100/FU650AD500-F100/FU660AD1500-F100/FU664AD2000-F100/FU671AD100-F100/FU671AD200-F100/FU671AD500-F100/FU671AD800-F100/FU671AD1000-F100 638/650/660/664/671nm 500mW~6000mW red laser diode module CW/TTL 30KHz <3% power stability TEM00 TEC big dimension
