More customized diode laser modules with different wavelengths and power options are available additionally to the standard types.
Brand: FU
Model: FU635AD700-GD10
Dot specification:
Wavelength(nM): 635±10
Output Power (mW): <700
Operating Voltage(VDC): 3
Projection Type : Dot/Point
Beam focus: Adjustable
Divergence (mrad, full angle): <2
Transverse Mode : Near TEM00
Operating Temperature Range (°C): -10 to +40
Storage Temperature Range (°C): -20 to +50
Total Power Consumption (W) 1
Cooling Method : Passive air+Heat sink
Cable length(cm): <100
Standard Warranty (months): 6
Laser Head Dimensions (mm): 35(L) x 10(D)
------------------
Package Includes:
Laser module -1 piece
Power supply- 1 piece
Tripod(Bracket/Mount)- 1 piece
Some of laser application:
FU635AD700-GD10 635nm 700mW red point dot laser module adjustable focus with 5.5*2.1mm DC connector
