FU915AD3000-F100/FU915AD8000-F100/FU940AD1000-F100/FU940AD2000-F100/FU940AD3000-F100/FU946AD100-F100/FU946AD200-F100/FU980AD1000-F100/FU980AD2000-F100/FU980AD3000-F100/FU980AD5000-F100 915nm 940nm 946nm 980nm IR laser

Product Title：FU915AD3000-F100/FU915AD8000-F100/FU940AD1000-F100/FU940AD2000-F100/FU940AD3000-F100/FU946AD100-F100/FU946AD200-F100/FU980AD1000-F100/FU980AD2000-F100/FU980AD3000-F100/FU980AD5000-F100 915nm 940nm 946nm 980nm IR laser

Note: Different model have different wavelength and output power

Model	FU915AD3000-F100 915nm 3000mW FU915AD8000-F100 915nm 8000mW FU940AD1000-F100 940nm 1000mW FU940AD2000-F100 940nm 2000mW FU940AD3000-F100 940nm 3000mW FU946AD100-F100 946nm 100mW FU946AD200-F100 946nm 200mW FU980AD1000-F100 980nm 1000mW FU980AD2000-F100 980nm 2000mW FU980AD3000-F100 980nm 3000mW FU980AD5000-F100 980nm 5000mW FU980AD8000-F100 980nm 8000mW FU980AD10000-F100 980nm 10000mW
Wavelength	See above
Spatial Mode	Near TEM00
Output Power	See above
Operation Mode	CW or Modulation
Beam Height	29mm
Beam Size	4.5*4mm
Beam Divergence(full angle)	1.2*0.5mrad
Power Stability	<3% per 4 hours
Temperature Stabilizing	TEC
Warm Up Time	<1 minute
MTTF	10,000 hours
Laser Head Dimension	1144465mm3 LWH
Power Supply	17914856mm3 LWH 85-265VAC 50/60Hz input
Modulation	0~30KHz Analog or TTL

FU915AD3000-F100/FU915AD8000-F100/FU940AD1000-F100/FU940AD2000-F100/FU940AD3000-F100/FU946AD100-F100/FU946AD200-F100/FU980AD1000-F100/FU980AD2000-F100/FU980AD3000-F100/FU980AD5000-F100/FU980AD8000-F100/FU980AD10000-F100 IR laser CW/TTL 30KHz <3% power stability TEM00 TEC
