Line specification:
Wavelength(nM): 520±20
Output Power (mW): <1200
Operating Voltage(VDC): 9~25
Projection Type : Line
Line's Fan angle(degree): 10~120
Beam focus: Adjustable
Divergence (mrad, full angle): <2
Transverse Mode : Near TEM00
Operating Temperature Range (°C): -10 to +40
Storage Temperature Range (°C): -20 to +50
Total Power Consumption (W) 1
Cooling Method : Extra heat sink
Cable length(cm): <100
Standard Warranty (months): 6
Laser Head Dimensions (mm): 110(L) x 22(D)
