Product Title:FU520ACX-GD1465 500-530nm 520nm <80mW 14x65mm adjustable green Cross hair line laser diode module

Brand: FU(For You)

Model: FU520ACX-GD1465


Cross Line specification:
Wavelength(nM): 520±20
Output Power (mW): <80
Operating Voltage(VDC): 3
Projection Type : Cross hair line
Beam focus: Adjustable
Projection Fan Angle(°, full angle) : 10~110
Divergence (mrad, full angle): <2
Transverse Mode : Near TEM00
Operating Temperature Range (°C): -10 to +40
Storage Temperature Range (°C): -20 to +50
Total Power Consumption (W) 1
Cooling Method : Extra heat sink
Cable length(cm): <100
Standard Warranty (months): 6
Laser Head Dimensions (mm): 65(L) x 14(D)
------------------
Package Includes:
Laser module -1 piece
Power supply- 1 piece
Tripod(Bracket/Mount)- 1 piece





FULASER-PROFESSIONAL LASER PRODUCT MANUFACTORY.

FU520ACX-GD1465 500-530nm 520nm <80mW 14x65mm adjustable green Cross hair line laser diode module
