Product Title：FU52015PXX50-GD16 510~530nm 520nm 510nm 50mW diverse line laser Diffractive optical elements(DOE) 15 multi lines parallel lines pattern with adjustable focus

Wavelength:  520nm in picture (405/450/520/532/635/650/670/685nm IR for choose)

Output power: <50mW

Operating voltage:  DC2.8~3.2V or 3.5~25V

Dimension:  φ16*70mm





Beam mode: 15 multi parallel lines(adjustable focus)

Lens:  Plastics lens

Operating temperature:  -10~40°C
Storage temperature:  -40-80°C
Beam size: @1000mm,  Line length: 670 mm, line width: 560 mm, line&line spacing: 40 mm (proportional scaling)





FU-Lasers for you!

FU52015PXX50-GD16 510~530nm 520nm 510nm 50mW Diffractive optical elements(DOE) 15 multi lines parallel lines pattern with adjustable focus diverse line laser
